Nested and keyed Beverage Can Dispenser for standard 7.5 oz “Mini” cans that holds 6 cans. I split it into two halves so it can be printed on a standard Prusa printer (MK3/MK4). The two halves are keyed together and glue is NOT required for it to stay together once in place. I have mine stacked four-high in my refrigerator, but can also be used two-high on shorter shelves.
I included “Full” versions for both sizes so anyone with a printer capable can print them in a single piece.
The assembled 6-can Dispenser is 4.81 inches wide x 13.92 inches deep x 3.22 inches high. (The cover only adds 0.03 inches to the overall height because it nests.)
I also included an optional cover for all versions so that items can be stacked on the Dispenser to maximize space efficiency. (see photos). I also think it makes the final product look cleaner in a kitchen. The covers are available in “slot” and “full” versions. The slot provides easier access to the cans in the top Dispenser (Thanks to @Justnice980 for the slot idea!)
Printed in PLA. No supports required except for the bottom of the cross-strut in the front half. You can see them in the Make photo I published.
Credits:
mhparsons
